Quiz Corner: Location of differential pressure flow transmitter for gas service

Where and how should a differential pressure flow transmitter be located for gas service?

I Stock 1039705312industryview
industryview/iStock

Where and how should a differential pressure flow transmitter be located for gas service?

A. Above the flow element with the impulse tubes sloping upward to the transmitter

B. Above the flow element with the impulse tubes sloping upward then downward to the transmitter

C. Below the flow element with the impulse tubes sloping upward then downward to the transmitter

D. Below the flow element with the impulse tubes sloping downward to the transmitter


Accurately transmitting the differential pressure generated by the flow element to the transmitter involves keeping the impulse tubing full of gas. Locating the transmitter below the flow element enables any liquid present to accumulate and potentially adversely affect accurate signal transmission of the differential pressure signal, eliminating Answers C and D. The downward sloping impulse tubing also eliminates Answer B. Thus, Answer A is correct.

Additional complicating factors

In some installations, it is not possible to install impulse tubes that constantly slope upward to the transmitter, so other means may be used to effect accurate transmission of the differential pressure signal. These include diaphragm seals or pots where liquid can accumulate without affecting the measurement.




David W. Spitzer is a principal at Spitzer and Boyes, LLC, which offers engineering, focused market research, writing/editing white papers, strategic marketing consulting, distribution consulting, seminars and expert witness services for manufacturing and automation companies. Spitzer has written more than 400 technical articles and 10 books about flow measurement, instrumentation and process control. He can be reached at 845-623-1830 or via spitzerandboyes.com.
